Spare Parts List - Bort BSS-18DC-Multicyclone Handbuch

A. Body components
1 Body lock
2 The female pin seat
3 Brush female pin
4 Suction seal
5 Dust cup lock spring
6 Dust cup lock
7 Body suction seal
8 Sponge
9 Middle baffle
10 Sponge
11 Sponge
12 Body rubber
13 Right body
14 Motor seal
15 Motor
16 Body pin
17 Body baffle
18 Motor support
19 Charger baffle
B. Dust cup assemble
1 HEPA shelf seal
2 Air inlet HEPA
3 Ventilation cover sealing strip

SPARE PARTS LIST

20 Lift body
21 Battery lock spring
22 Battery lock
23 Handl down cover
24 Body down cover
25 PCB
26 Power button
27 Handl up cover
28 PCB
29 Led cover
30 Led baffle
31 Sealing ring
32 Cup support
33 Cover air flue
34 Body cover
35 Aluminum tube bottom lock
spring
36 Aluminum tube bottom lock
4 Ventilation cover inside
5 Ventilation cover
6 Spring
21
