Step 3: Drill wall hole for connective piping
1. Determine the location of the wall hole based
on the position of the mounting plate. Refer
to Mounting Plate Dimensions.
2. Using a 65mm (2.5in) or 90mm (3.54in)
(depending on models) core drill, drill a
hole in the wall. Make sure that the hole
is drilled at a slight downward angle, so
that the outdoor end of the hole is lower
than the indoor end by about 5mm to
7mm (0.2-0.275in). This will ensure proper
water drainage.
NOTE: When the gas side connective pipe is
16mm (5/8in) or more, the wall hole should
be 90mm (3.54in).
3. Place the protective wall cuff in the hole.
This protects the edges of the hole and
will help seal it when you finish the
installation process.
CAUTION
When drilling the wall hole, make sure
avoid wires, plumbing, and other
to
sensitive components.
MOUNTING PLATE DIMENSIONS
Different models have different mounting plates.
For the convenience of installation, there are
bubble level, carved dimensions on the
mounting plate. Please install the plate and drill
wall hole according to the information of the
mounting plate. See the figures below.
BUBBLE
LEVEL
50 2
100 mm 50 50 100
100 4
4 inch 2 2 4
LIQUID GAS
mm inch
150 6
RECOMMAND
Unit: mm
Horizontal direction ruler
100 mm 50 50
2
4 inch 2
LIQUID GAS
BUBBLE
LEVEL
CAUTION: The Bubble level on the mounting
plate can't be removed. If it is broken, make
sure to clean up the leaking liquid.
pipe hole
65
50
Models 9 / 12
BUBBLE
LEVEL
50
2
100 mm 50
pipe hole
100 4
2
4 inch
LIQUID
65
mm inch
150 6
RECOMMAND
50
Model 18
50 2
mm
100 50
4
100
2
4 inch
LIQUID GAS
mm inch
150 6
RECOMMAND
50
pipe hole
65
Model 24
82
50 2
100
4
100
Vertical direction
4
ruler
mm inch
150 6
RECOMMAND
425
pipe hole
65
120
795
490
50 100
2
4
GAS
95
965
570.7
BUBBLE
LEVEL
100
50
2
4
70
pipe hole
1140
pipe hole
65
65
