Control Board

The Control Board offers several features: you can easily set the starting address, run the pre-programmed
program or select a DMX channel mode.
device has an automatic storage for all settings. When you switch the device off and on again, it will operate
with the previously set values.
Default settings in bold
MAIN level Menu level
DMX Addr 001-512
3 CH, 4 CH, 6CH,
DMX Chan
8CH, 11CH
OFF/Dim1/Dim2/
Dimmer
Dim3/Dim4
Mas/Slav Master/Slave
Power – ON/OFF
Wireless
Unlink
Red – 000 - 255
Color Set
Green – 000 - 255
Blue – 000 - 255
White – 000 - 255
Col Mac R – R+G+B+W
The main menu is accessed by pressing Menu. Browse through the
menu by pressing Up or Down. Press Enter in order to select the
desired menu. You can change the selection by pressing Up or Down.
Press Enter in order to confirm. You can leave every mode by pressing
Menu. The functions provided are listed in the following sections.
If you press and hold UP or DOWN, the values changes faster. The
Description
DMX address setting
Setting DMX channel mode
Dimmer speed (step response)
OFF: Response characteristics of LEDs
Dim1: Response characteristics of halogen lamps, fast
Dim2: Response characteristics of halogen lamps, less fast
Dim3: Response characteristics of halogen lamps, middle
Dim4: Response characteristics of halogen lamps, slow
Master/Slave mode
ON: Activate WDMX
OFF: De-activate WDMX
Disconnect
Press ENTER for 3 seconds to delete the wireless connection.
Dimmer intensity of the LED colors /
stepless RGBW color mixture 000 – 255 (increasing)
Dimmer intensity red
Dimmer intensity green
Dimmer intensity blue
Dimmer intensity white
Preset colors
R
G
B
W
R+G
28/36
R+B R+G+B
R+W R+B+W
G+B G+B+W
G+W R+G+W
B+W R+G+B+W
