INSTALLATION
WARNING! Risk of injury caused by falling objects
Devices in overhead installations may cause severe injuries when crashing down. Make sure
that the device is installed securely and cannot fall down. The installation must be carried out by
a specialist who is familiar with the hazards and the relevant regulations.
The device may be placed on the floor by unfolding the brackets or fastened to a truss or similar rigging
structure. The device must never be fixed swinging freely in the room.
1
The rigging structure must support at least 10 times the weight of all fixtures to be installed on it.
2
Block access below the work area and work from a stable platform when installing the device.
3
Use rigging hardware that is compatible with the structure and capable of bearing the weight of the
device. Please refer to the "Accessories" section for a list of suitable rigging hardware.
4
Secure the device with a safety bond or other
secondary attachment. This secondary safety
attachment must be sufficiently dimensioned in
accordance with the latest industrial safety
regulations and constructed in a way that no
part of the installation can fall down if the main
attachment fails. An appropriate eyelet is
mounted on the device for fixation of the safety
bond. Fasten the safety bond in such a way
that, in the event of a fall, the maximum drop
distance of the device will not exceed 20 cm.
5
To align the device, release the fixation screws
at the mounting bracket, adjust the desired
inclination angle and tighten the fixation screws.
6
After
installation,
inspections periodically to prevent the possibility
of corrosion, deformation and looseness.
7
Make
sure
the
connections are always closed when using the
product outdoors.
Changing the beam angle
With the delivery of the device you will receive two frost filters, with which the beam angle can be changed
from 8° to approx. 15° or 19°. If you want to change the beam angle of the device, attach the desired filter
using the two knurled screws to the front of the device. Make sure the screws are tightened to prevent
accidental release of the frost filter.
the
device
requires
protective
caps
of
the
25/36
00128030, Version 1.0
