Combination possibilities

Combinations of
ACU 3 gases
with no display
electronics
ACU 3 gases with
display electronics
ACU 5 gases
equipped with
1 to 3 gases
ACU 5 gases
equipped with
4 to 5 gases
Integration into the
Alarm Management
System
Housing
Monitor 3G - Basic Monitor 6G - Basic
Direct connection of Direct connection of
switch gauge from one switch gauge from
ACU 2 ACUs
Connection via relay Connection via one
module (G 18989) for relay module each
one multi-messaging (G 18989) for one
signal per gas type multi-messaging signal
from one ACU per gas type from
2 ACUs
Connection via relay Connection via one
module (G 41742) for relay module each
high and low alarm per (G 41742) for high and
gas type from one ACU low alarm per gas type
from 2 ACUs
Not all gases Connection via two
can be displayed relay modules
(G 41742) for high and
low alarm per gas type
from one ACU
Transmission of signals Transmission of signals
to the Alarm to the Alarm
Management System Management System
via optional transceiver via optional
(G 50719) transceivers
(2 x G 50719)
AP set 130 (G 50744) AP set 250 (G 50745)
UP set 130 (G 50740) UP set 250 (G 50741)
Operation
Monitor 3G - AMS
Not possible
Connection via
network line from
Monitor G from one
ACU
Connection via
Alarm System Interface
(G 41743)
from one ACU
Not all gases
can be displayed
Transceiver for Alarm
Management System
already installed
AP set 130 (G 50744)
UP set 130 (G 50740)
Monitor 6G - AMS
Not possible
Connection via
network line from
Monitor G from
2 ACUs
Connection via
Alarm System Interface
(G 41743)
from 2 ACUs
Connection via
Alarm System Interface
(G 41743)
from one ACU
Transceiver for Alarm
Management System
already installed
AP set 250 (G 50745)
UP set 250 (G 50741)
