Fastening the hob

Very important: It is vital that you ensure the glass ceramic hob is built into a perfectly
flat supporting surface. Deformations due to improper fastening could alter the
characteristics of the hob and compromise its performance.
Take particular care in ensuring the seal surrounding the hob is correctly in place,
in order to avoid any leaks into the supporting cabinet.
Fixing brackets
Hob from below
Fixing brackets
Hob top
Cut out
Fixing brackets
Worktop
