MSA EVOLUTION 5600 Kurzanleitung Seite 2

LED indicators
Battery charging status indicator
Status indicator
Overheating warning
Switching on in normal mode
(1) Press ON / OFF button for approx. 1 second.
(2) Direct the camera towards an object or person until the
Changing over to standby mode (energy saving mode)
(1) Keep ON / OFF button pressed until the display switches off
(2) Changing back to normal mode: press ON / OFF button
Switching off
(1) Keep the ON / OFF button pressed for approx. 4 seconds
Replacing the Batteries
(1) Hold the camera upside down, such that the battery
(2) Open the lock, unhook the battery compartment latch and
(3) Place charged battery in the battery compartment.
(4) Close the battery compartment lid, hook on the latch and
GB
Downloaded from www.Manualslib.com
LED green
LED yellow
LED red
LED red flashing
LED green
LED green flashing
LED off
LED off
LED red flashing
thermal image is shown on the display.
and the green status LED flashes.
again until the display switches back on and the LED status
remains continuously illuminated green once again.
until all LED indicators switch off.
compartment faces upwards.
open the lid.
close the lock.
manuals search engine
= fully charged
= 50 % residual capacity
= residual capacity for approx.
15 min more
= empty
= Camera is switched on
= Energy saving mode
= Camera is switched off
= Operational temperature range
= Overheating danger
Order No.: 10084447/00
