* Using the unit continuously for a long time may result in blinking of the overheat indicator due to excessively
high temperature of LEDs. (Temperature warning)
With the occurrence of temperature warning, it is recommended to conduct light irradiation for the maximum
5 minutes and then take intermission for the period equivalent to the irradiation time. The maximum settable
time is 5 minutes with temperature warning being displayed.
* A further rise in temperature results in a temporary stop of the full mode for giving the LEDs intermission, and
operation restarts automatically when the LEDs suffi ciently cool down. Pressing the stop key or leaving the
door opened resets the remaining time.
4) The remaining time of "0" indicates the end of curing.
The end is also indicated by fi nish sound and display of "Fin."
Upon verifying the display, open the door and remove the object.
■ Do not remove a composite immediately after curing directly with hands in the full mode. Otherwise, burn
injury could be caused by the hot composite.
< Recommended curing position in the full mode >
Place an object subject to curing within the hatched
area as shown in the diagram.
(Hatched area: Inside the circle with a diameter
of about 70mm directly above the turntable, and a
height of 25 to 80mm from the upper surface of the
turntable)
1) A prosthesis alone such as crown and bridge
/ A prosthesis placed on a model equipped with dowel pin
Use "Curing stand"and "Curing stand holder"
(For more detail on the Curing stand, see Section 5.4)
70mm directly
(Recommended curing position)
Downloaded from www.Manualslib.com manuals search engine
CAUTION
Dia. 70 mm
25-80 mm
Dia. 70 mm
70mm
55mm
