Clearaudio Unify Bedienungsanleitung Seite 8

User manual / Bedienungsanleitung
Pic. 7: Placing the anti-skating weight
9. VTA adjustments are accomplished by loosening the two lock screws an the side of the armboard
base (approx. at the 10:00 and 2:00 positions). Once loosen, you can moove the arm up or down
to achieve the desired VTA.
Please tighten both screws when finished and re-check tracking force after adjusting VTA.
Pic. 9: Screw one for VTA
10. Azimuth adjustments are facilitated through the small allen screw on the bottom side of the
armwand where the headshell enters the carbon fibre. Once you loosen this screw, you´ll be
able to rotate the headshell a small amount in either direction. Be sure to tighten the screw when
done.
Pic. 11: Allen screw on the bottom side of the armwand
8
Downloaded from www.Manualslib.com
Pic. 8: Placing the anti-skating weight
manuals search engine
Pic. 10: Screw one for VTA
© clearaudio electronic GmbH, 2018/10
Green arrowhead =
slower anti-skating
Red arrowhead =
stronger anti-skating
