CVM-C5
3�4�5�- MESSUNG IN DREIPHASEN-STROMKREISEN MIT 3-DRAHT-ANSCHLUSS UND
SPANNUNGSWANDLERN IN ARON-SCHALTUNG�
V
L1
a
A
L1
L2
L3
LOAD
Abbildung 6: Dreiphasen-Messung mit 3-Draht-Anschluss und Spannungswandlern in ARON-Schaltung�
ModellCVM-C5-MC-IC:
DerfesteWertderSekundärwicklungdesMC-Transformatorsbeträgt0,250A�
