3.2 Space and ventilation requirements

3.2.1 Space requirement

Observe the possible lateral space requirement of the open door relevant to the
door opening angle.

3.2.2 Ventilation

Observe the required minimum distances for proper ventilation.
NOTICE! Fix the plastic wall spacers (depending on model) on the
condenser at the back of the appliance to ensure an adequate ventilation
gap between the appliance and the wall.
M
Downloaded from www.Manualslib.com
S
PACE REQUIREMENT OF THE APPLIANCE
A = Depth / B = Width / C = Depth ( when the door is open)
A
569 mm 554 mm
INIMUM DISTANCES REQUIRED FOR PROPER VENTILATION
Back ↔ wall
Sides ↔ wall
Free space above
manuals search engine
B C
ca. 1123 mm
41
:
Height
1430 mm
:
min. 20 mm
min. 20 mm
min. 100 mm
