Performing Current Measurements
To perform current measurements, set up your
multimeter as shown in the figure below. For
measuring DC current from a mixed signal in DC
measurement mode, ensure that the Filter is
enabled.
Measuring AC current
1 Set the rotary switch to
Press
display.
2 Connect the red and black test leads to input
terminals µA.mA (red) and COM (black) or
A (blue) and COM (black) respectively.
3 Probe the test points in series with the circuit
and read the display.
10
manuals search engine
to ensure
Keysight U1251B and U1252B Quick Start Guide
or .
is shown on the
