How to Install the Monitor

Mounting precautions

• Since the monitor is heavy, consult your dealer before
installing, removing or moving the monitor.
• When installing, removing or moving the monitor, ensure
that this is carried out by at least 2 people.
• A stand and mounting bracket compliant with VESA
specifications is required. Do not use any screw holes other
than VESA holes for installation.
• When moving the monitor, be sure to hold it with the
handles both on the rear and the unit bottom. Do not hold
the LCD panel. This may cause product damage, failure, or
injury.
• Install the monitor with the surface perpendicular to a
level surface. If necessary, limit the tilt between 0 and 20
degrees downward.
• Mounting the monitor on the wall requires special expertise
and the work must be performed by an authorised SHARP
dealer. You should never attempt to perform any of this
work yourself. Our company will bear no responsibility
for accidents or injuries caused by improper mounting or
mishandling.
• This monitor should be used at an ambient temperature
between 0°C and 40°C. Provide enough space around the
monitor to prevent heat from accumulating inside.
For the monitor in horizontal orientation
20
5
5
For the monitor in vertical orientation
20
5 5
5
* The monitor can be installed close to a wall, etc.
However, the monitor emits heat during operation. Be
aware that heat emitted from the monitor may discolour
or alter the wall.
If it is difficult to provide such space because the monitor is
installed inside a housing or for other reasons, take other
measures to keep the ambient temperature between
0°C and 40°C such as installing a fan in the housing.
Unit: cm
*
5
Unit: cm
*
• Adhere to the following when installing the monitor in the
vertical orientation. Failing to adhere to the following may
cause malfunctions.
- Install the monitor such that the power LED is located on
the downside.
- Set the MONITOR on the SETUP menu to PORTRAIT.
(See page 19.)
• Do not block any ventilation openings. If the temperature
inside the monitor rises, this could lead to a malfunction.
• After mounting, it is recommended to take some measures
to prevent the monitor from falling down.
• Do not place the monitor on a device which generates heat.
• Be sure to use a stand or a wall-mount/ceiling-mount
bracket designed or designated for mounting the monitor.
• This monitor is designed to be installed on a concrete wall/
ceiling or pillar. Reinforced work might be necessary for
some materials such as plaster / thin plastic board / wood
before starting installation.
This monitor and bracket must be installed on a wall which
can endure at least 4 times or more the weight of the
monitor. Install by the most suitable method for the material
and the structure.
• Use the supplied vertical logo sticker when you install the
monitor in vertical orientation.
*
INPUT
* Do not remove the factory-affixed sticker but affix the logo
sticker over it. Be careful not to cover the remote control
sensor or buttons.
9
E
