ItsImagical Aracno-Bot Montageanleitung Seite 13

Inhaltsverzeichnis

Werbung

STEP
19
P8 (Air Cathode)
1 Black
Side Up
B2
Make sure the above 3 parts placed in correct sequence and position.
STEP
20
Cut off the 2 burrs
before assembly.
B5
P9 (Nonwoven Fabric)
B5
(Fuel Cell Plate)
P12
P10 (Magnesium Sheet)
Cut off the 3 burrs
before assembly.
B2
