Introduction
Thank you for choosing the 915P/G Combo2 V2.0 (MS-7140 v2.X) Series ATX mainboard. The
915P/G Combo2 V2.0 Series is based on Intel 915P/G & Intel ICH6 chipsets for optimal system
efficiency. Designed to fit the advanced Intel
package, the 915P/G Combo2 V2.0 Series delivers a high performance and professional
desktop platform solution.
Layout
Downloaded from www.Manualslib.com
T: mouse
B: keyboard
CPUFAN1
T: Line-In
M: Line-Out
B:Mic
CD1
Codec
JAUD1
PCI_E1
PCI_E2
RTL8100C/
RTL8110S
PCI Slot 1
Winbond
W83627THF
PCI Slot 2
PCI Slot 3
BIOS
JCOM1
manuals search engine
®
P4 Prescott 533/ 800MHz processors in LGA775
JPW1
BATT
+
FDD1
JUSB2 JUSB1
1
SYSFAN1
ATX1
IDE1
SATA4
JBAT1
SATA2
SATA1 SATA3
JFP2
JFP1
