MATRIX 430
®
QUICK START GUIDE
SETUP THE CONSOLE
1. On guidance screen, press NAVIGATION AND GUIDANCE OPTIONS tab
display options.
2. Press HOME button .
3. Press CONSOLE button
X LCD Brightness
X Colour Scheme
X Units
CONFIGURE THE MACHINE
4. From the Home screen
5. Select and configure a Machine profile
X Select Machine Profile Number
profile that is "active" is displayed/active on the operation screen.
X Set Number of Implement Sections
implement sections. Range is 1 to 7 sections.
X Set Section Widths – used to enter the width of each section. Each
C
section can be a different width.
X Set Lateral Implement Offset Distance
distance from the centre line of the machine to the centre of the implement.
– Positive value will move the implement to the right of centre while facing in
the machine's forward direction.
– Negative value will move the implement to the left of centre while facing in
the machine's forward direction.
X Set In-Line Implement Offset Distance
from the GNSS antenna (the zero point) to the implement.
– Positive value will move the implement behind the GNSS antenna.
– Negative value will move the implement in front of the GNSS antenna.
6. Select Lighbar Spacing
or vehicle each guidance screen lightbar box represents.
7. Set GNSS configuration
NOTE: When using the Matrix 430 in Europe, always work with GPS and
GLONASS. Use SBAS (EGNOS) where applicable.
