Manual screen adjustment

Adjustments can be made using On Screen Display
(OSD) Menu provided.
1. Display an image that makes the entire screen
very bright. If using Windows, you can open and
use the Adjustment Pattern on the accompanying
Utility Disk. (p. 17)
2.Press the MENU button.
The ADJUSTMENT Menu will be displayed.
A DJ U S TMENT
MANU AL
CL OC K 127
P H ASE
H- POS 200
V- POS
1 0 2 4 X 7 6 8
V : 7 5 H z H : 6 0 . 0 k H z
At this point relevant menu options can be
adjusted.
Each time the MENU button is pressed the next
menu is selected. (ADJUSTMENT → GAIN
CONTROL → WHITE BALANCE → MODE
SELECT → OSD Menu disappears)
Notes:
- The OSD Menu automatically disappears
approximately 30 seconds after the last
command.
- This explanation is based on using the
Adjustment Pattern (for Windows) to make
adjustments.
Adjusting the screen display
ADJUSTMENT Menu
MANUAL: Individual menu options are manually
AUTO:
AU TO
Notes:
16
-
29
-
-
CLOCK
The figure below demonstrates how to adjust so that
vertical flicker noise is not emitted. (
PHASE
The figure below demonstrates how to adjust so that
horizontal flicker noise is not emitted. (
Note:
-
H-POS (horizontal positioning) and V-POS
(vertical positioning)
To center the screen image within the boundaries of
the screen, adjust the left-right (H-POS) values and
the up-down (V-POS) values. (
18
A D J US T MEN T
MANU AL
C L OC K 1 2 7
PH A SE 16
H- P O S 2 0 0
V - P O S 2 9
1 0 2 4 X 7 6 8
V : 7 5 H z H : 6 0 . 0 k H z
adjusted.
Every menu option is automatically
adjusted.
Press the button to select [AUTO].
To choose a menu option:
To go to the next menu: MENU button
Vertical flicker noise
Adjustments to PHASE should be made only
after CLOCK has been correctly set.
Horizontal flicker noise
A UT O
SELECT button
buttons)
buttons)
buttons)
Screen frame
