Handwheel
rotations
2
3
4
5
6
7
8
Fig. 6 DN 25
Handwheel
rotations
2
3
4
5
6
7
8
Fig. 8 DN 40
2
Kv-Value
0.9
2.0
3.5
5.0
6.1
6.7
7.0
Kv-Value
2.2
4.7
8.9
13.2
16.4
19.3
21.0
VI.B1.N3.7I
Fig. 7 DN 32
Fig. 9 DN 50
© Danfoss 8/2004
Handwheel
Kv-Value
rotations
2
1.3
3
3.0
4
5.8
5
9.2
6
12.3
7
14.6
8
15.8
Handwheel
Kv-Value
rotations
2
2.5
3
8.8
4
17.0
5
26.2
6
34.5
7
40.2
8
43.9
7369348-0 SIBC
