3. Music Control (Soud)
To select the music control via the built-in microphone, press the "Menu" button until "Soud"
appears in the display. Then press the "Enter" button to confirm the selection. The display will
now show "Senx (0 to 9)". Press the "Up" and "Down" buttons to adjust the microphone
sensitivity.
4. color mode (Colr)
To select the manual color mode, press the "Menu" button until "Colr" appears in the display.
Press the "Enter" key to confirm the selection. The individual colours can then be selected:
Alternatively, preset colors can also be selected in the color mode. Use the "Up" and "Down"
keys until "CCxx (1 to 20)" appears in the display. Press the "Enter" key to edit the preset
colors. Press the "Up" and "Down" buttons to select a preset color. Then press the "Enter"
button to confirm the selection.
To adjust the strobe effect in color mode, press the "Up" and "Down" buttons until "Stxx (0 to
99)" appears in the display. Then press the "Enter" key to confirm the selection. You can then
adjust the strobe effect speed using the "Up" and "Down" buttons. Then press the "Enter" key
to confirm the selection.
5. master/slave mode
To set the devices to slave mode, press the "Menu" button until the display shows "SLAu". Now
press the "Enter" button to confirm the selection.
6. DMX mode
To select the individual DMX channels, press the "Menu" button until "dnH" appears in the
display. Now press the "Enter" key to confirm the selection. Press the "Enter" button again to
display the selected channel mode (CH 4, CH 6 or CH 8). Now press the "Up" and "Down"
buttons to select a channel mode. Then press the "Enter" key to confirm the selection.
rxxx (0-255)
Setting the color intensity of the color Red
gxxx (0-255)
Setting the color intensity of the green color
bxxx (0-255)
Setting the color intensity of the blue color
uxxx (0-255)
Setting the color intensity of the color White
ENGLISH
