Installation - simu T3.5 AUTO Originalbetriebsanleitung

GB T3.5 AUTO / T5 AUTO - 230V - 50Hz
S.A.S. au capital de 5 000 000 € - Z.I. Les Giranaux - BP71 - F70103 Arc-Les-Gray CEDEX - RCS VESOUL B 425 650 090 - SIRET 425 650 090 00011 - n° T.V.A CEE FR 87 425 650 090

Installation

1
- Recommendations:
- The motor torque must be selected according to the shutter's characteristics. Do not oversize the operator.
- The use of automatic locking devices (VAR, VAS or EASYLINK) and stops on the fi nal slat is mandatory in order to ensure proper working of the motor.
- To receive information regarding the compatibility of the motor and the roller shutter or/and accessories, contact the roller shutter manufacturer or SIMU.
- Drilling of the tube:
L1
29
Ø38,2
L2
T3.5 AUTO
4.12
230V-50Hz
9.12 - 13.8
Assembly T3.5 AUTO :
2
Wiring
N
L
PE
- 3 operators (max.) can be wired in parallel on one switch.
- The wiring has to be realized by trained people (T5 AUTO).
- The motor does not allow connection with an emergency power supply such as regulated power supply or power generating unit.
- The connector has to be assembled without damaging the contacts. The continuity of the earth connection must be ensured (T5 AUTO).
- Please do contact SIMU when using KNX / EIB electronic switching control devices.
3 Power up of the operator
After the fi rst two consecutive opening and closing of the shutter :
- The motor memorizes automatically the end limit ( up and down) positions.
- The "stop on obstacle" function is activated.
>>
- It is advised to carry out these two opening / closing cycles as soon as the product is installed.
- For any further information, please consult the SIMU technical leafl et 5056893.
4 Cancelling the automatic settings
- In the case of a new installation with this operator, it is advised to reset the motor according to the following procedure:
>> >>
1 s 1 s
- Press 3 consecutive times, for 1s each time, on the UP key. The motor runs briefl y at each press.
- Press 3 consecutive times on the DOWN key. The fi rst two press for 1s (the motor runs briefl y at each press) and the third press for 2s. The motor runs twice in the same
direction.
A
A ØB
(mm) (mm) (mm)
433 457
4.2
473 497
Ø4 x 10 / 120°
STEEL
T3.5 AUTO
>>
>>
1 s
4 x ØB / 90°
55 22,8
37
min.
48*
L1 L2
(mm)
* 35 Nm max.
T5 AUTO
471
511
230V-50Hz
Noise level : LpA ≤ 70 dB (A)
Assembly T5 AUTO :
9910013
9910014
25 N.m max.
N
Blue
Brown
L
Black
PE
Green/yellow
>>
1 s
5052442D
Read carefully these instructions before any use.
L1
4
L2
(mm)
6.17 - 10.17 485
15.17
505
20.17 - 25.17 - 35.17 659
1
2
3
1
OK
>>
>>
>> >>
1 s
V.A.R
V.A.S
EASYLINK
MANDATORY
A
4 x ØB / 90°
47
min.
A ØB L1 L2
(mm) (mm) (mm)
498 521
5
518 541
672 695
5
Ø4,8 x 10
STEEL
4 Ø5 x 10
3
2
1
1
2
2
35 N.m max.
T5 AUTO
1
2
>>
3
>>
>>
2 s
1/1
