Num'axes PIE1045 Gebrauchsanleitung Seite 21

Before inserting or removing the SD card, the camera must be turned off (switch in the
OFF position). Failing to do so may cause loss of or damage the files already recorded on
the memory card.
When the SD card is full, the LCD screen indicates "Memory full".
5. Viewing files on a TV
The camera can transfer the video signal to an external monitor or a television set.
- Connect the TV to the AV port on the bottom of the camera with a TV out cable (not
supplied).
- Put the camera switch in the SETUP position.
- After connecting, the camera enters the playback mode and the LCD screen turns off.
The registered videos will be shown on the TV.
See the TV owner's manual for more information.
6. Customizing the settings
Slide the switch to the SETUP position (the LCD screen will light up) then press the MODE
button 4 times to enter the setting menu.
In the setting menu, you can check and change the settings of the camera.
You can navigate the setting interface by pressing  and . Press "OK" to enter parameters
or to save a setting. Press the MODE button to exit to the previous page.
Settings
Mode
Image size
Multi-shot
PIE1045 - Indice B – Mars 2020
Programmable options (default settings in bold characters)
Photo / Video / Photo + Video
− Photo: the camera shoots only photos.
− Video: the camera shoots only videos.
− Photo + Video: upon the same trigger event, the camera shoots
a photo first then a video.
24MP (5640x4232) / 20MP (5120x3840) / 16MP (4608x3456) /
12MP (4032x3024) / 10MP (3648x2736) / 8MP (3264x2448) /
5MP (2592x1944) / 3MP (2048x1536) / 2MP (1920x1440)
Higher resolution produces better quality photos but creates
larger files that take up more of the SD card capacity (fills up
faster).
1 photo / 2 photos / 3 photos
You can program 1 up to 3 photos per trigger
21/76
