Repairing punctures

Changing the tires after puncture does not differ much from tire changes
for ordinary bikes. Only the rear wheel needs special attention when
assembling or removing it. This manual presupposes a certain skill set for
repairs or tire changes. If this is not the case for you, please contact your
local Coboc dealer.
Turn your Coboc bike off ("bike off", lights off)! Prior to any
maintenance or repair work, make sure that your Coboc bike is
turned off. The motor might start unexpectedly during the repair
or motor plug contacts might be under power. This could cause serious
injuries.

Removing the rear wheel:

• Shift to the smallest sprocket the highest gear. Your rear derailleur
has a locking system that facilitates the removal of your rear wheel.
Simply push the lever forward and press the locking button (1).
The lever should now lock in place and there should be no tension
on the chain anymore.
• Disconnect the motor plug (2) and release the cable holder in
direction of the motor (3).
• Remove the plastic caps (4) on the axle nuts.
• Loosen the axle nut with an open-end spanner (spanner gap of
18mm) and remove the drive side axle nut and washer. Make sure,
that the rear wheel does not fall out of place uncontrolled, as soon
as you have loosened the screws.
• You can now completely remove the rear wheel by pulling it out
downwards.
• Tire change can now be carried out just like with an ordinary bike.
Maintainance & Care
(4)
(5)
(3)
(3)
(2)
(1)
