4.2 Handling

In order to prevent any damage to the device, it is recommended to
transport it exclusively inside its original packaging.
We recommend:
- not to bump the device (even if still in its packaging) exposed to atmospheric agents.
- not to drag the device.

4.4 Product identification

Figure 4 shows the identification label containing the serial number which must always
be provided when requesting assistance, spare parts, repairs or information
concerning operation of the device.
The identification plate is applied to the device and must be legible. It is
forbidden to remove it or to tamper with its data. Should it be damaged
or lost, ask the manufacturer to have it replaced with a new one.
Remember that the warranty is linked to the identification number of the
product.

5. Installation and connections

5.1 Installing the reading head

The installation of the WorldKey UltraLite is simple. It is sufficient to make a 33 mm
diameter hole with a hollow mill. Once the vending machine metal sheet has been
pierced, insert the reader and fix it using the relevant nuts supplied (42 nuts).
Screw all the way without using any wrenches.
There is a projection on the perimeter of the reading head to prevent the round frame
from turning.
.Figure 4
