Specifications - Emos T3 Handbuch

GB T3 THERMOSTAT
The T3 thermostat is designed to monitor and control heating systems. It is equipped with a timed
room temperature reduction (SET-BACK) function with repetition every 24 hours. It is a simple system
of temperature control in a designated area. The thermostat is designed for indoor use. It is typically
located in places such as offices, schools, shops, houses, etc.

Specifications

Range of temperature control: 5 °C to 30 °C
Maximum switching load: 7 A resistive, 3 A inductive
Power supply: 230 V AC 50/60 Hz
Set-back timing: 6 h/day repeated
Control switches: MCV controlled by on/off relay
System indication: Green LED indicates that the Set-back function is active. When the Set-back temper-
ature is to drop by 5 °C, the LED is orange.
Operating temperature: 0 °C to 40 °C
Storage temperature: -20 °C to 60 °C
Dimensions: 97 × 67 × 28 mm
ON indicator
L (live) N (neutral)
Install while power supply is OFF
2
