Vortice LINEO serie Betriebsanleitung Seite 51

21
WIRING TO AN EXTERNAL GENERATOR SIGNAL 0-10V
P0
PI
P10
S1
S2
R1
R2
1 2 POLES SWITCH (DPST)
2 EXTERNAL GENERATOR SIGNAL 0-10V
3 DRY CONTACT FOR ALARM SIGNALLING
(250VAC, max current 3A)
22
LINEO V0 ES 100, 125, 150, 160, 100Q, 200, 250
1
2 POLES SWITCH (DPST)
2
POTENTIOMETER
( FROM 5 KOHM TO 10 KOHM)
3
ON/OFF SWITCH (SPST)
DRY CONTACT FOR
4
ALARM SIGNALLING
(250VAC, max current 3A)
LINEO 315 V0 ES
NOTES
1) Don't remove wire connected between contact "N"
PCB of PCB and contact "3" of terminal block on cover
2) Don't remove wire connected between contact "L"
of PCB and contact "4" of terminal block on cover
N L
GND
OUT (0-10V)
2
3
WIRING TO AN EXTERNAL POTENTIOMETER
PCB Control Port Description
---------------------------------------
P0 = Potentiometer 0V = GND
PI = Potentiometer Input Signal = 0-10V
P10 = Potentiometer 10V = +10V
S1-S2 = dry contact for MAX/MIN speed
R1-R2 = dry contact for optional Alarm
L2
N1
COVER
PCB Control Port Description
---------------------------------------
P0 = Potentiometer 0V = GND
PI = Potentiometer Input Signal = 0-10V
P10 = Potentiometer 10V = +10V
S1-S2 = dry contact for MAX/MIN speed
R1-R2 = dry contact for optional Alarm
PCB
N L
P0
PI
P10
S1
S2
R1
4
R2
4
3
1
N
L
1
L
N
2
3
