Wartung; Machine Components; Recommended Accessories; Safety Instructions - SUHNER LSB 70 Originalbetriebsanleitung

unbedingt auf die zulässige Drehzahl achten.

Wartung

• Maschine trocken und sauber aufbewahren.
Leerlaufdrehzahlen periodisch kontrollieren.
• Schiebeventil ölen.
• Beanstandungen können nur anerkannt werden,
wenn die Maschine unzerlegt zurückgesandt
wird.
Technical Data
at 90 PSI Operation Pressure
Power
Torque
Air consumption
full load
Air consumption
no load
No load speed
Sound pressure level
according to ISO 15744
Vibration according to
EN ISO 28927-12
Weight without hose
Recommended air quality
according to DIN ISO 8573-1
Air hose ID
Collets
(refer to catalog) US only
Governor

Machine components

1 Full bore pin throttle
2 Insulted turbine housing
3 Guide rest
4 Spindle
5 Collet
6 Clamping nut
7 Wrench 14 mm
8 Exhaust hose
9 Air hose
Zubehör
Das Zubehör mit den dazugehörigen Bestellnum-
mern ist in den
Änderungen vorbehalten.

Recommended Accessories

GB
10 Coupling with min ID 5.o mm / 3/16"
11 1/2" -Service Unit (capacity 5 Micron).
220 Watt 12 A
0.05 Nm
28,0 cfm
3
0,8 m /min.
17,5 cfm
3
0,25 m /min.
70000 rpm
Suitable Tools
71 dB(A) Refer to tool list (not available for North America).
14 Mounted points. Attention: always observe
2
3.3m/s /K=2.0
15 Use only solid carbide burs (US only with max.
0,42 kg
2/4/3

Safety Instructions

• Do not exceed max. operating speed of tool and
8 mm 5/16"
• Observe accurate mounting of insert tools.
up to 1/4" • Observe mounting instructions for Mounted
up to 1/8"
• Run tool for a couple of seconds under no load,
installed
• Secure work, use clamp or vise to hold work.
• The grinder operator shall wear safety goggles
• If noise level exceeds 85 dB(A) at the work stati-
For additional safety instructions refer to enclosed
brochure 30006072.
-Katalogen aufgeführt.
In-line Air Filter, part no. 907 632 is pre-
installed on the US Version (refer to enclosed
operating manual).
The European In-Line filter version LF 05
part no. 57 710 01- G 1/4" needs to be added if
air couplings 13 are used to guarantee trouble
free operation.
Operation tool without In-line filter cancels any
warranty claim.
mounting instructions.
1/8" shank dia.)
clamping element.
Stones!
replace vibrating insert tools at once, protect
mounted points from knocks and grease.
or face shield at all times when the grinder is in
operation.
on, operator must use ear protection (plugs and/
or ear mufflers).
3
