Figure A: 315 Dc Machine Assembly - Saf-Fro PRESTOTIG 315DC Bedienungsanleitung

Item Description
1 FRONT FRAME
2 REAR FRAME
3 BOTTOM FRAME
4 WRAPAROUND
5 FRONT PANEL
6 BACK PANEL
7 CONTROL P.C. BOARD
8 DISPLAY P.C. BOARD
9 INPUT P.C. BOARD
9A + INPUT RECTIFIER
10 INVERTER P.C. BOARD
10A + POWER IGBT
10B + POWER RESISTOR
11 OUTPUT P.C. BOARD
11A + OUTPUT DIODE
11B + DOUBLER BRIDGE
11C + POWER RESISTOR
12 HF P.C. BOARD
13 HALL SENSOR
14 THERMOSTAT SENSOR
15 OUT INDUCTOR
16 OUT TRANSFORMER
17 HF TRANSFORMER
18 SWITCH
19 INPUT CORD
20 KNOB
21 FAN
22 WATER COOLER CONNECTOR
23 TRIGGER TORCH CONNECTOR
24 REMOTE CONTROL CONNECTOR
25 DINSE CONNECTOR
26 ASSEMBLE CAP. 4n7 250Vac
27 ASSEMBLE CAP. 47nF 2000Vdc
28 SOLENOID VALVE
29 FITTING 1/4-1/8 + NUT 1/4
30 FITTING QUICK CONNECTION PU 1/8
Spare Parts - Electrical Schematic

Figure A: 315 DC Machine Assembly

Part Number
R-8040-425-1R
W93X1362R
W93X1421R
R-1019-518-1R
R-0010-681-1R
R-0010-682-1R
W05X1329-2R
W05X1330-2R
W05X1328R
W4100012R
W05X1327-1R
W4300070R
W1810010R
W05X1326-2R
W4010040R
W4100020R
W1810010R
W05X1615R
W4900004R
W9600081R
W58X1336R
W59X1334R
W59X1401R
W7511707R
W78X1201R
R-8040-431-1R
W66X1369R
W6861008R
W6860032R
W6860030R
W7690350R
W66X1248R
W66X1407R
W8500011R
W8896074R
W8800082R
2
QTY 1 2 3 4
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
4 X
1 X
1 X
3 X
1 X
1 X
1 X
1 X
2 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
1 X
2 X
1 X
1 X
1 X
1 X
1 X
Spare Parts - Electrical Schematic
5 6
