Connections
Connecting to PC
A Connect the AC adapter to the burner.
B Connect the power cord to the AC adapter.
C Connect the power cord to an AC outlet.
D Press the power button /B) on the front to turn on the burner.
(C
The power lamp lights in green.
E Turn on the PC.
F Connect the burner to the PC with the USB cable.
NOTE:
To connect the burner to a PC, use the USB cable provided with the camera.
PC
E
F
USB Cable (provided for the camera)
AC Adapter
(provided for the burner)
D
F
Rear of burner
A
To USB Connector
B
Power Cord
(Provided)
C
To AC Outlet
EN 5
