Specifications

Monitor Specifications
LCD Module
Viewable Image Size:
Native Resolution (Pixel Count):
Input Signal
Display Colours
Viewing Angle
Synchronization Range Horizontal:
Resolutions Supported Landscape:
Active Display
Area (Lanscape)
Active Display
Area (Portrait)
Power Supply
Current Rating
01b_English
MultiSync LCD1850DX Monitor
Diagonal:
46 cm/18.1 inches
46 cm/18.1 inches
1280 x 1024
Video:
ANALOG 0.7 Vp-p/75 Ohms / Digital Input: TMDS
Sync:
Separate sync.TTL Level
Horizontal sync. Positive/Negative
Vertical sync. Positive/Negative
Compostite sync. Positive/Negative
Sync on Green (Video 0.7 Vp-p and Sync 0.3 Vp-p)
Analog input: 16,777,216
Left/Right:
± 85°
Up/Down:
± 85°
31 kHz to 82 kHz
Vertical: 50 Hz to 85 Hz
1
720 x 400* : VGA text
1
640 x 480* at 60 Hz to 85 Hz
1
800 x 600* at 56 Hz to 85 Hz
832 x 624* 1 at 75 Hz
1024 x 768* 1
1152 x 870* 1
1280 x 1024*
1
480 x 640* at 60 Hz to 85 Hz
Portrait:
1
600 x 800* at 56 Hz to 85 Hz
1
624 x 832* at 75 Hz
768 x 1024* 1
870 x 1152* 1
1024 x 1280*
Horizontal:
359 mm/14.1 inches
Vertical: 287 mm/11.3 inches
Horizontal: 287 mm/11.3 inches
Vertical:
359 mm/14.1 inches
AC 100-120 V/220-240 V 50/60 Hz
0.8 A @ 100-120 V, 0.35 A @ 220-240 V
English-22
22
Notes
Active matrix; thin film
transistor (TFT) liquid
crystal display (LCD);
0.28 mm dot pitch;
240cd/m
typical; 300:1 contrast ratio,
typical
Depends on display card
used.
Automatically
Automatically
Some systems may not
support all modes listed.
at 60 Hz to 85 Hz
at 75 Hz
2 at 60 Hz to 75 Hz
at 60 Hz to 85 Hz
at 75 Hz
2 at 60 Hz to 75 Hz
Dependent upon signal
timing used, and does not
include border area.
Dependent upon signal
timing used, and does not
include border area.
26/3/01, 12:12 pm
2
white luminence,
