EngLIsh
DO nOt use under wet conditions or in the presence of
flammable liquids or gases.
This screwdriver is a professional power tool.
DO nOt let children come into contact with the tool.
Supervision is required when inexperienced operators use
this tool.
Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
This product is not intended for use by persons (including
children) suffering from diminished physical, sensory or
mental abilities; lack of experience, knowledge or skills
unless they are supervised by a person responsible for their
safety. Children should never be left alone with this product.
Electrical Safety
The electric motor has been designed for one voltage only.
Always check that the battery pack voltage corresponds to the
voltage on the rating plate. Also make sure that the voltage of
your charger corresponds to that of your mains.
Your D
WALT charger is double insulated in
e
accordance with EN60335; therefore no earth wire
is required.
If the supply cord is damaged, it must be replaced by a
specially prepared cord available through the D
service organisation.
Mains Plug Replacement
(U.K. & Ireland Only)
If a new mains plug needs to be fitted:
Safely dispose of the old plug.
Connect the brown lead to the live terminal in the plug.
Connect the blue lead to the neutral terminal.

WARNING: No connection is to be made to the
earth terminal.
Follow the fitting instructions supplied with good quality plugs.
Recommended fuse: 3 A.
Using an Extension Cable
An extension cord should not be used unless absolutely
necessary. Use an approved extension cable suitable for
the power input of your charger (see Technical Data). The
minimum conductor size is 1 mm
is 30 m.
When using a cable reel, always unwind the cable completely.
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.

WARNING: Use only D
e
28
WALT
e
; the maximum length
2
WALT battery packs and chargers.
Inserting and Removing the Battery Pack
from the Tool (Fig. C)
nOtE: Make sure your battery pack
To Install the Battery Pack into the Tool
Handle
1. Align the battery pack
 6
with the rails inside the tool's
handle (Fig. C).
2. Slide it into the handle until the battery pack is firmly seated
in the tool and ensure that you hear the lock snap into place.
To Remove the Battery Pack from the Tool
1. Press the release button
 7
out of the tool handle.
2. Insert battery pack into the charger as described in the
charger section of this manual.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicable regulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can cause injury.
Proper Hand Position (Fig. A, E)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position as shown.

WARNING: To reduce the risk of serious personal injury,
ALWAYS hold securely in anticipation of a sudden
reaction.
Proper hand position requires one hand on the main handle
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
tool off, release the trigger switch. Your tool is equipped with a
brake. The chuck will stop as soon as the trigger switch is fully
released.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes or fasteners.
nOtE: Continuous use in variable speed range is not
recommended. It may damage the switch and should be
avoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
the tool and also serves as a lock-off button.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
the tool.
To select reverse, depress the forward/reverse control button on
the left side of the tool. The center position of the control button
 6
is fully charged.
and firmly pull the battery pack
 5
 1
. To turn the
determines the direction of
 2
.
