RECEIVER RGB CONTROLLING LED COMMON KATHODE
Product code:
TVRGB000M01
1 - led wiring
24Vdc Driver
Slave
input
Slave output
Warning
Connect the power supplier and the LED RGB in a correct way to the receiver before
connecting the power supplier to the electricity network.
A faulty connection of the LED diodes (polarity inversion) could damages them, therefore pay
attention during their connection by respecting the polarity. The general power supply of the
device has to be by a power supplier which can supply the power and tension needed.
At the power-on-reset the condition previous the turning-off will be resumed.
The product must not be enclosed or placed with insulating material such as
glass wool, polystyrene or similar materials. Let the housing to be well-ventilated.
In the view of a constant development of their products, the manufacturer reserves the right
for changing technical data and features without prior notice.
TECHNICAL SPECIFICA TIONS
-Power supply
-Current on the RGB outputs
-Max. power for each output
-N° LED connectable for each out 1/6
Code Number:
TVRGBD000M01-N01
TELECO AUTOMATION SRL -
++39.0438.388511 FAX: ++39.0438.388536 - www.telecoautomation.com
TELEPHONE:
This document is the property of T eleco Automation Srl who reserves all reproduction and copying rights
Slave receiver 350mA TVRGB000N01
Master
TVRGB000M01/N01
TVRGB000M01
TVRGB000N01
24 Vdc, 21W
24Vdc, 45W
350 mA
700 mA
7 W
15 W
1/6
Series
TVLink RS868
Via dell'Artigianato, 16 - 31014 Colle Umberto (TV) ITALY
-
Common
Slave output
-Cable sections in input and output
-Operating temperature range
3
Slave receiver 700mA
Attention:
respect the
leds polarity
1,5 mm
-20° - +60°C
Model number
T427.01
2
03/02/2011
