Ausgangsimpedanz
150 Ω
Integriert Digitalsignalverarbeitung
Pro Kanal Equalizer (4-Band-parametrisch), Stummschaltung, Polarität umkehren, Gain (140 dB Bereich)
System Audio-Summierung
Vernetzung
Voraussetzungen für Kabel
Cat 5e oder höher (Abgeschirmtes Kabel empfohlen)

IP Ports and Protocols

Shure Control
Port TCP/UDP Protocol
21 tcp FTP
22 tcp SSH
23 tcp Telnet
68 udp DHCP
80* tcp HTTP
443 tcp HTTPS
161 tcp SNMP
162 tcp SNMP
2202 tcp ASCII
5353 udp mDNS
5568 udp SDT
8023 tcp Telnet
8180 tcp HTML
8427 udp Multcast SLP
64000 tcp Telnet
Aux
Mikrofon
Description
Required for firmware updates (otherwise closed)
Secure Shell Interface
Not supported
Dynamic Host Configuration Protocol
Required to launch embedded web server
Not supported
Not supported
Not supported
Required for 3rd party control strings
†
Required for device discovery
†
Required for inter-device communication
Debug console interface
Required for web application
†
Required for inter-device communication
Required for Shure firmware update
Shure Incorporated
- 20 dB
-46 dB
Factory De­
fault
Closed
Closed
Closed
Open
Open
Closed
Closed
Closed
Open
Open
Open
Closed
Open
Open
Open
