Operating instructions
LCD Hour meter
C C O O D D I I X X 1 1 3 3 4 4 / / 1 1 3 3 5 5
The Codix 134/135 are battery-powered LCD hour
meters. They can be used for various applications.
Typical uses are for example: operating time and lifeti-
me measurement, passage time measurement, time
Overview
Model Operating
mode
6.134.012.8x0 Timer
6.134.012.8x1
6.134.012.8x3
6.135.012.8x0 Timer
6.135.012.8x1
6.135.012.8x3
Table 1
DC operating modes:
Timer: INP A: no function
INP B: Timer-Enable-Input
Main technical features:
Display: LCD, 8 decades, height of the figures 8 mm
Display range:
0 ... 99999999 with leading zeros
suppression.
Accuracy: < 100 ppm
Overflow:
In case of a display range overflow, the
timer starts again from 0, but without remo-
ving the leading zeros and activating all
decimal points.
Keys: Electrical locking of the reset key
Housing: Panel mounting, 48 x 24 mm
according to DIN 43 700, RAL 7021
Panel cut-out:
+0,3 +0,6
22,2 x 45 mm
Mounting depth:
approximately 48 mm
Weight: approximately 50 g
Protection level:
IP65 on the front side
monitoring, etc.
They are controlled by means of dry contacts or volta-
ge pulses.
Time range Inputs
INP A
99999h 59 m/ ––
99999.99 h
10 ... 260 V AC/DC
9999 h 59 m 59 s/ ––
9999999.9 s
10 ... 260 V AC/DC
Options:
AC operating modes:
Timer:
Connection:
EMC:
Low Voltage Directive (for the AC models):
Power supply:
Working temperature:
Operating temperature:
Storage temperature:
Backlighting:
INP B
00 ... 0,7 V DC
04 ... 30 V DC
AC/DC 10 ... 260 V AC/DC
00 ... 0,7 V DC
04 ... 30 V DC
AC/DC 10 ... 260 V AC/DC
x = 5: no backlight
x = 6: with backlight
INP A: Timer-Enable-Input AC/DC
INP B: reset input AC/DC
Screw terminals, RM 5.00, 8 poles
Rated cross-section: 4,0 mm 2
2
2,5 mm thin wire AWG 12
Connection diameter:
0,4 ... 2,3 mm single-wire
AWG 28-12
Interference emissions EN55011 Class B
Interference resistance EN 61000-6-2
EN 61010 Part 1 ; overvoltage category 2,
contamination level 2
Non-replaceable lithium battery
(lifetime approximately. 8 years at 20°C)
–10 ... +55 °C, relative humidity < 85%,
without condensation
–10 ... +60 °C
–20 .. +70°C
must be powered by an external elecrical
source (24 V ±20%, 50 mA)
NPN
PNP
AC/DC
NPN
PNP
AC/DC
single-wire
