Electric Scheme - Desoutter SLB030 series Ursprüngliche Betriebsanleitung

6159933893_08
Series: B

ELECTRIC SCHEME

A'
5
1
6
4
2
3
A' B'
Receptacle Cable
1 Yellow
2 Black
3 Black
4 Blue
5 Red
6 Green
CN2
B'
1
2
3
4
5
6
E'
D'
C'
CN2
Connector
1
2
3
4
5
6
6 / 60
F'
BLDC
control
board
A Receptacle
'
B
Cable
'
CN2
Connector
C
Changeover switch
'
D Stop switch
'
E Start switch
'
F BLDC Control board
'
G Motor
'
G'
M
