• D+, D−: Data positive and data negative connection of the
databus. Remote units can be up to 1.5 km from the ATS
control panel.
•
IN: A request to exit button (normally open, momentary
push- button switch) can be connected across "IN" and
"−". When pressed, this button controls the request to exit
function.
•
OUT: Open collector output, 50 mA maximum. It is the first
output of the output control group that is assigned to this
arming station.
Links
See Figure 1.
•
GND (item 2): Must remain fitted.
•
TERM (item 5): Fitted if this device is the last device on
the system databus. For more details see the ATS control
panel installation guide.
Connection from electronics to keypad
See Figure 1, item 1.
Via a standard cable supplied with this product.

Specifications

Supply voltage
Maximum operating current
Dimensions
Operating temperature
Maximum relative humidity
Regulatory information
Manufacturer UTC Fire & Security Americas Corporation, Inc.
3211 Progress Drive, Lincolnton, NC, 28092, USA
Authorized EU manufacturing representative:
UTC Fire & Security B.V.
Kelvinstraat 7, 6003 DH Weert, Netherlands
Product warnings THESE PRODUCTS ARE INTENDED FOR SALE
and disclaimers TO AND INSTALLATION BY QUALIFIED
PROFESSIONALS. UTC FIRE & SECURITY
CANNOT PROVIDE ANY ASSURANCE THAT
ANY PERSON OR ENTITY BUYING ITS
PRODUCTS, INCLUDING ANY "AUTHORIZED
DEALER" OR "AUTHORIZED RESELLER", IS
PROPERLY TRAINED OR EXPERIENCED TO
CORRECTLY INSTALL FIRE AND SECURITY
RELATED PRODUCTS.
For more information on warranty disclaimers and
product safety information, please check
https://firesecurityproducts.com/policy/product-
warning/
Certification
UTC Fire & Security hereby declares that this
device is in compliance with the applicable
requirements and provisions of the Directive
2014/30/EU and/or 2014/35/EU. For more
information see www.utcfireandsecurity.com or
www.interlogix.com.
2 / 16
10.5 to 13.8 V
70 mA
118 x 75 mm
0 to +50°C
95% noncondensing
or scan the QR code.
2012/19/EU (WEEE directive): Products marked
with this symbol cannot be disposed of as
unsorted municipal waste in the European Union.
For proper recycling, return this product to your
local supplier upon the purchase of equivalent
new equipment, or dispose of it at designated
collection points. For more information see:
www.utcfssecurityproducts.eu/recycle/
Contact information
www.utcfireandsecurity.com or www.interlogix.com
For customer support, see www.utcfssecurityproducts.eu
DA: Installationsvejledning
Montering af enheden
Enheden leveres som et kit bestående af et tastatur og seperat
elektronikmodul. RAS Kodetastaturet kan overflademonteres
eller hvis ønsket i et kundespecifikt kabinet.
Bemærk: Monter enheden i en passende højde, så den er
nem at betjene og LED'erne er synlige.
Tilslutning af centralenhed til ras
kodetastatur
Se figur 3.
I installationsmanualen til ATS-centralen finder du en
vejledning.
Indstillinger for RAS-dipswitch
Se figur 2.
SW1 "Adress" switch1 til 4 (figur 1, punkt 4) bruges til at
indstille RAS-adressen.
LED's
TX (figur 1, punkt 3): LED blinker for at angive, at RAS
kodetastaturet svarer på polling fra ATS-centralen.
LED-indikationer på RAS kodetastaturet
• ACCESS (Frakoblet): Lyser, når mindst ét af de områder,
der er tildelt RAS kodetastaturet, er frakoblet. Når der
bruges en PIN-kode til at åbne en dør, blinker LED'en,
i den tid døren er låst op.
• ALM (Alarm): Lyser, når en alarm har været udløst i ét af
de områder, der er tildelt til RAS kodetastaturet.
•
RDY:
- Lyser når området er klar til at blive tilkoblet (system
klar), dvs. at alle zoner er normale, eller
- hvis RAS kodetastaturet er tilsluttet til et 4-dørs/elevator
DGP, vil den lyse, når den er klar til at acceptere en PIN-
kode.
• SECURE (Tilkoblet): Lyser, når området er tilkoblet.
Når alle LED's blinker, polles RAS kodetastaturet ikke.
P/N MAINST-ATS1155 (ML) • REV C • ISS 19JUN18
