Before taking into operation for the first time, the installation has to be approved by an expert!
Procedure:
Step 1: Unscrew the housing cover counter clockwise.
Step 2: Remove the housing cover.
Step 3: On the baseplate, there are holes for the installation.
Step 4: Hold the baseplate onto the location where the device is to be installed.
Step 5: Mark the boreholes with a pen or a suitable tool.
Step 6: Drill the holes.
Step 7: Hold the baseplate in the desired position and tighten it.
Step 8: Attach one end of the connection cable with phone jack RJ11 in the socket of the Master Control
Box. Take care not to cover any part of the LED ring.
Step 9: Have the device connected to the mains. The occupation of the connection cables can be seen in
the following table.
Step 10: After installing the device and connecting it to the mains, replace the housing cover and screw it
clockwise back in place

DANGER TO LIFE!

Do not operate this device with opened housing cover!
