OVEN AND ACCESSORIES

9
8
7
10
11
I
•
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to
ensure that it is not damaged.
• Always operate the oven with the turntable and roller stay fitted correctly. This promotes
thorough, even cooking. A badly fitted turntable may rattle, may not rotate properly and
could cause damage to the oven.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each
time you start the oven. This does not affect cooking performance.
• When you order accessories, please quote both the PART NAME and MODEL NUMBER to
your dealer or SHARP approved service facility.
WARNING:
The door, outer cabinet, oven cavity, turntable and dishes will become very
hot during operation. To prevent burns, always use thick oven gloves.
0
I
3
4
6
5
•
•
'
•
C 0
OVEN
1. Oven lamp
2. Control panel
3. Door opening button
1
4. Waveguide cover (DO NOT REMOVE)
5. Oven cavity
2
6. Coupling
7. Door latches
8. Door hinges
9. Door seals and sealing surfaces
10. Power cord
11. Ventilation openings
12. Outer cabinet
ACCESSORIES:
12
Check to make sure the following accesso-
ries are provided:
13. Turntable
14. Roller stay
• Place the roller stay in the coupling on the
oven floor, then place the turntable on to
the roller stay, ensuring it is located firmly.
• To avoid turntable damage, ensure dishes
or containers are lifted clear of the turn-
table rim when removing them from the
oven.
GB-3
