Water Pre-Installation; Cold/Hot Water Connections - SYSTEMPOOL VERSATILE series Vormontage-Installation

VERSÂTILE
MODELS: V-105 / V-503 / V-506 / V-511
On this model the position of the headrest ( only one position ) is fixed. The version is given by this position
of the headrest.
POSITION

COLD/HOT WATER CONNECTIONS

Refer to tables 2, 3, 4, 5 and 6 to consult the sizes corresponding to the positions of the different types of tap
fittings
- The min. supply pressure for the cold/hot water inside the stall will be 2 Bar.
- The max. supply pressure for the cold/hot water inside the stall will be 5 Bar.). A and B
A) RIM
PRE-INSTALLATION MANUAL
CHOOSING A POSITION FOR THE VERSÂTILE BATH
Left
Wall
Center / Free-standing
V-503
Center / Free-standing
Left
Wall

WATER PRE-INSTALLATION

V-105
V-511
- Place the 3/4 G male connection points at the
cold and hot water outlets in the positions indica-
ted by the symbol
between connection points. Fig. 1, 2, 3, or 5.
6
Right
Enter
V-506
Center / Free-standing
Right
. Leave a maximum of 5 cm
EN
