VERSÂTILE
To the election of versatile bath, different criteria should be taken into account depending on the bath mo-
del.

MODELS: V-102 / V-103 / 104

VERSION
The version of the bath its given by the position of the headrest. Once we know the version of the bath, then
choose the corresponent panels depending on installation position.
POSITION
If the bath is put in a corner to the left its location will be of left, and vice versa.
PRE-INSTALLATION MANUAL
CHOOSING A POSITION FOR THE VERSÂTILE BATH
LEFT
LEFT
RIGHT VERSION
Frontal Panel and
2 Laterals (F + 2L)
Frontal Panel and Left
Panel (F + LI)
LEFT VERSION
Frontal Panel and
2 Laterals (F + 2L)
Frontal Panel and
Left Panel (F + Li)
RIGHT
PANELS
5
RIGHT
Frontal Panel and
Right Panel (F + LD)
Frontal Panel (FF)
Frontal Panel and
Right Panel (F + Ld)
Frontal Panel (FF)
EN
