ENGLISH
Installation
Power
Link/Act
LED Indicator
Status
LED Indicator
On Power is on.
Power
Off Power is off.
On Port is connected
Blinking Transmitting / Receiving data
Link/Act
Off Port is not connected
Connecting Equipment
Step1. Inspect the Power Adapter carefully, and make sure
that it is properly connected to a power source.
Step2. Plug‐in the Power Adapter to the Switch.
Step3. Connect your network devices with the switch by
using Ethernet cable. (e.g. Cat‐5e)
Power Input
MS220‐48: 100‐240V, 50‐60HZ, 1.1‐0.6A
MS220‐48LP: 100‐240V, 50‐60HZ, 5.7‐2.4A
MS220‐48FP: 100‐240V, 50‐60HZ, 10‐4.1A
Operating Temperature
0~40℃
SFP
Meaning
