• Set of accessories for "Cobra/Mamba/Zoom"
Note
If you are not yet using a set of accessories, skip the following steps: 2 c, 3c, 4b.
Customer complaints
• No claims may be made for natural wear and tear or for damage caused by undue demands
on the product or by exceeding the permissible load.
• No claims may be made for damage caused by improper use.
• No claims may be made for damage caused by incorrect assembly or operation.
• No claims may be made for damage caused by improper modifications to the product.
• Mildew is likely to appear on textiles which are not dried out after getting wet and cannot be
attributed to shortcomings in production conditions.
• The product may fade if exposed to sunlight, perspiration and detergents, or if subject to
abrasion or excessive washing, therefore fading cannot be attributed to a fault with the
product.
1. Contents
a. Seat liner
b. Hood cover
c. Guard rail cover
2. Seat liner
a. To open the harness, press the button on the side.
CAUTION: Always use the shoulder harness and lap belt together.
b. Release the seat belt padding from the Velcro fastener and pull it under the belt clips of the
shoulder
belt.
Open the belt clips by pressing in the two buttons on the sides.
Remove the seat belt padding.
c. Remove the back fastening above the seat unit. Now you can remove the seat liner at the
openings through which the shoulder belts and the crotch strap are pulled through.
d. To attach the seat liner, thread it through the shoulder belts and the crotch strap and attach
the back
fastener above the seat unit.
e. Pull the shoulder belts through the seat belt padding.
Close the shoulder belt by pushing the two belt clips together.
Pull the seat belt padding over the belt clips and fasten these to the Velcro fastener.
f. To fasten the harness, bring the top two plastic catches together and interlock them.
Then insert the interlocked catches into the bottom part of the fastening.
Adjust the harness to a setting where the baby is held in the correct
3. Hood
a. Remove the hood
b. To fit the hood cover you must first remove the hood holder on one side by pulling back the
lever on the hood holder.
You can press the lever outwards from the inside using a screwdriver or another pointed
object.
c. Pull out the hood cover from the open side.
d. To attach the hood cover, you must thread it through the open side.
e. Then you can push on the hood holder.
f. Fit the hood on the seat frame with the two plastic brackets.
EN - 03
