4. Repeat steps 1 through 3 for the remaining rack rail.
Figure 4. Installing the rack rails
M5 attaching screws
Rack front post
Rack rear post
5. Pick up the appliance and line-up the chassis rails on the rear of the
appliance with the front rack rails.
See page 8, Figure 5.
6. Slide the appliance into the rack.
If needed, press the locking tabs on the chassis rail to slide the appliance
into position.
When you have pushed the appliance all the way into the rack, the locking
tabs make a "click" sound.
Task 2: Mounting the Appliance in a Rack
7
