VTrak S3000 Quick Start Guide
Figure 10.Subsystem rack mount assembly diagram
Rack front post
Inside of post
Note that only the front rail has a support for the subsystem.
Alignment pins
two on each flange
Rear rail
Front rail
Support for
subsystem
Rail attaching screws
(not included)
26
Rack rear post
Inside of post
