Pulse output (optional)
The pulse output, passive and polarity dependent,
needs a separate power supply and that the polarity is
correctly wired
to energy consumed.

Trouble Shooting

Check following carefully before contacting you vendor
Load indicator is not rotating
- the current going through the meter is too low
Load indicator is going anti clock wise
- the current is going through the meter backwards
No pulses given (Meters with pulse output only)
- Separate power supply missing or not working
properly
- Wrong polarity
- Load is to low (too long time between the pulses)
Installation check / Error codes
Error code Reason
100-107 Meter internal error
300 Voltage exceeding
maximum voltage
301 Voltage below
minimum voltage
302 Amperage exceeding The meter can be damaged
maximum amperage
303 Frequency is wrong
501-502 Date / Time is missing Set correct date / time
700-705 Meter internal error
For more details see: DELTAsingle User's Manual.
. Pulses generated are proportional
9
45
Recommended Action
Contact supplier
The meter can be damaged
Reduce voltage immediately
Increase voltage to ensure the
meters full functionality
Reduce amperage immediately
Check network frequency
Contact supplier
