Functions

2.1 The display shows consumption in kWh.
2.2 LED (at the front of the meter),
frequency 1000 imp/kWh.
2.3 Load indicator
exceeds the starting current (25 mA).
Push buttons
To switch between the different modes and/or
programming use the two buttons Set and Scroll
Button Function (activated when button is released) Symbol
Set To move to Set mode and to change
values
Scroll Normal Scroll – to move between the
menus or step within a menu.
Scroll Long Scroll (press Scroll for more than
two seconds) – to move between normal
and alternative mode. Long Scroll is also
used to discontinuing programming and
return to normal mode.
Display modes
Explains the display information. NOTE, tariff and
clock settings, only on meters with clock and/or tariff
functionality.
DELTAsingle has three display alternatives:
(See sketch 8)
- Normal mode - Showing energy consumption.
- Alternative mode - Showing additional information.
- Set mode - Showing and changing programmed

settings.

rotating when the load
3.1
41
3.5
with flashing
1.5
S
Sc
LSc
