Special Applications - Dictator DIREKT 200 Montageanleitung

6. Blocking and compressing
Turn adjusting screw Compress the
clockwise until the doorcloser
end min. 50 mm
8. Provide mechanical stop in position OPEN,
otherwise:

Special applications:

Use on
smaller than 65 mm
both sides, if
!
Adjust the pressure,
only when absolutely necessary!
(only with inox)
O-ring
bearing bush
(not with inox)
Adjustment/ Maintenance
V - "summer"
V + "winter"
according to season
Last test:
Mechanical stop in position OPEN? End with adjustment screw on door? Screws fixed? Moving parts greased? Customer instructed?
7. Fix the DIREKT and adjust the closing speed
Fix this end
always at the
pillar
Distance X
min. 560 mm
min. 580 mm
Door OPEN
Wall
protective
glasses
WG slightly glued!
gloves
1 - 2 x per year
Ø33
Ø28
Ø28
Bearing bush in case of
zinc-plated, white and black finish
Pillar
SOFTLY 2-4 times
fix Direkt
and
repeat, if necessary
grease
V -
Ø33
V +
End with adjustment
screw always on door!
mechanical stop
Door OPEN
larger than 50 mm
max. 100 gram
mixture of
oil and gas
refix
1 x per year
Direkt.Montage.200.S2.09.10.2008
