Installation Instructions door closer DIREKT 200 with eyelets or ball bearings
1. Determine starting point
Dimensions in mm
Dimension B
Pillar
Example 1
Dimension A 105
Dimension B: acceptable between 30 and 70
Example 2
Dimension A 135
Dimension B : acceptable between 30 and 45
2. Provisional installation of the brackets
A .
B
possible adjust-
ment of the bracket
C .
Step B : reduce value of dimension A and Step C : move again
4. Assemble the bracket and align it
Tel : 0821 / 24673-0 Fax : 0821 / 24673-90 Email : info@dictator.de
Dimension A
in mm
160
150
140
Gate
130
120
110
100
90
80
70
60
50
40
B .
Move this end until
obtaining:
not with:
Dictator Technik Gutenbergstraße 9 86356 Neusäß
10
20 30 40
50
60 70 80
Min.
Max.
choose the
A
max. value for A
max. 740 mm
max. 760 mm
If the distance is smaller:
5. Fixing
Gate
4 x hexagon M 6
Fixing brackets
Dimension
B in mm
3. Control of dimensions when
the gate is open
distance
min. 560 mm
min. 580 mm
buffer
with:
door
Direkt.Montage.200.S1.09.10.2008
Pillar
Gate
2 x countersunk
head screws M6
with:
