ronment. However, these components are required for
the correct operation of the device. Devices marked by
this symbol are not allowed to be disposed of together
with the household rubbish.
Working with detergents may only be performed on
watertight surfaces with connection to the waste
water sewage system. Do not allow detergent to enter
waterways or the soil.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.de/REACH
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
Check the contents for completeness when unpacking.
The scope of delivery for your equipment version is
shown on the packaging. Please contact your dealer if
any accessories are missing or in the event of any ship-
ping damage.

Safety instructions

CAUTION
● Do not use the device when
persons are in the vicinity of
the cleaning head.
● Switch the high-pressure
cleaner off and disconnect the
T-Racer from the high-pres-
sure gun after finishing clean-
ing work and before
performing any work on the T-
Racer.
● Do not trigger the high-pres-
sure jet at the high-pressure
gun until the T-Racer is on the
surface to be cleaned.
● Recoil danger. Keep proper
footing and hold the high-pres-
sure gun and extension tube
firmly.
● Maximum water temperature
60°C (please observe the in-
structions for your high-pres-
sure cleaner).
6
Note
● Be sure to always adhere to
the safety instructions for your
high-pressure cleaner and the
locally applicable regulations
and directives.
Symbols on the device
Risk of injury! Never reach under the
edge of the T-Racer during operation
HARD For durable surfaces, e.g. tiles, concrete,
stone
SOFT For sensitive surfaces, e.g. wood
Device description
For the illustrations, refer to the graphics page
Illustration A
Extension tube
1
Rotor arm height adjustment
2
Casing
3
Bayonet connector with union nut
4
Handle
5
High-pressure nozzle
6
Rotor arm
7
Extension tube installation
Note
Ensure that the device components are tightly connect-
ed on installation.
Illustration B
1. Plug the bayonet into the mounting.
2. Turn the extension until it latches into place.
3. Tighten the union nut.
Repeat the procedure for all further extension tubes.
Selection of the high-pressure nozzles
Using the appropriate high-pressure nozzles is a pre-
requisite for fault-free operation.
Note
These are to be selected according to the flow rate (l/
min). Information on the flow rate is provided in the op-
erating instructions or on the type plate of the high-pres-
sure cleaner.
Note
The yellow high-pressure nozzles are already fitted.
Flow rate l/min (l/h) High pres-
Less than 5.8 (348)
5.8 (348) - 7.5 (450)
Greater than 7.5 (450) K6 - K7
English
DANGER
Initial startup
Colour of the
sure class high-pressure
(e.g.) nozzles
K2 - K3 Green
K3 - K5 Grey
Yellow
