Electronic Switch-Off Delay
After turning the rotary hammer off, the extraction system will
run for a few seconds longer to vacuum the remaining dust
particles in the internal parts and collect the dust in the dust
collection box.
Adjusting the Telecope to Match the Drill Bit
Length (Fig. A)
1. Insert the appropriate drill bit.
2. Pull the telescope 6 out and hold it at the maximum length
of travel.
3. Press and hold the adjustment for drill bit length button
on the side of the dust extractor and retract the telescope
so that the dust extractor head
drill bit.
4. Release the adjustment for drill bit length button and
telescope. The telescope will click and lock in position.
5. To reset the telescope press the adjustment for drill bit
length button and extend the telescope out as far as it
will go. Release the adjustment for drill bit length button
and telescope.
Adjusting the Drill Bit Depth (Fig. A)
1. Insert the appropriate drill bit.
2. Retract the telescope 6 so that the required length of
drill bit is protruding past the dust extractor head
matches the desired hole depth.
3. Press and hold the depth adjustment button
back along the length of the telepscope as far as it will go.
4. Release the depth adjustment button and the telescope.
The telescope will now not extend past the set depth.
5. To reinstate the maximum drilling depth press and hold the
depth adjustment button and slide it all the way to the end
of the telescope. Release the depth adjustment button.
Emptying the Dust Collection Box (Fig. F, G)

WARNING: Wear approved eye protection and approved
dust mask when performing this procedure.

CAUTION: Do not clean with water or compressed air.
The dust collection box should be emptied as soon as the
1
performance has noticeably decreased or is full.
1. Press the dust collection box release buttons
dust collection box away from the dust extraction system.
Once the catch mechanism is clear of the dust extraction
system the upper joint will also release allowing the dust
collection box to be removed completely.
2. To empty the dust collection box
suitable container to catch the dust contained within it.
Lift up the assembly release latch
collection box, separating the canister from the lid. Gently
tapping the dust collection box will encourage any dust
trapped within the filter to also be removed. Once the filter
lid and canister are empty reattach them, ensuring the
16
5
10 meets the end of the
10 and
4 and slide it
2 and pull the
1 position it over a
15 to open the dust
assembly release latch
15
Figure G.
3. To reattach the dust collection box to the dust extraction
system first insert the rounded profile of the upper joint
into the recess on the dust extraction system. Pivot the dust
collection box down so that the release buttons click back
into place. Refer to Figure F.
4. With the dust collection box properly installed, depress
the filter cleaning mechanism
the tool. Allow the system to run for 5 seconds and release
trigger. This should be done after every emptying of the
dust collection box.
MAINTENANCE
Your D WALT power tool has been designed to operate
e
over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper tool
care and regular cleaning. Empty the dust extractor periodically
or when the performance has noticeably decreased.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or removing/
installing attachments or accessories. Be sure the
trigger switch is in the OFF position. An accidental start-up
can cause injury.
Replacing the Dust Collection Box Filter
Assembly (Fig. F)

WARNING: Wear approved eye protection and approved
dust mask when performing this procedure.
nOtE: The filter should be replaced after every 350 cycles
of use.
1. Press the dust collection box release buttons
dust collection box away from the dust extraction system.
Once the catch mechanism is clear of the dust extraction
system the upper joint will also release allowing the dust
collection box to be removed completely.
2. Discard dust collection box
3. Reattach the dust collection box to the dust extraction
system. First insert the rounded profile of the upper joint
into the recess on the dust extraction system. Pivot the dust
collection box down so that the release buttons click back
into place.
Lubrication
Your dust extractor requires no additional lubrication.
Cleaning

WARNING: Wear approved eye protection and approved
dust mask when performing this procedure.

WARNING: Do not use a brush or compressed air to clean
the dust collector or filter.
is securely fastened. Refer to
and pull the trigger on
3
2 and pull the
replace with a new filter box.
1
