Superstructure
Boom
11 m - 33,5 m four-section, full-power sequenced synchronized boom.
Maximum tip height: 36,4 m.
*Optional Fixed Swingaway Extension
10,1 m offsettable lattice swingaway extension. Offsettable at 0°, 25° and 45°. Stows
alongside base boom section. Maximum tip height: 45,8 m.
**Optional Bi-Fold Swingaway Extension
10,1 m - 17,1 m bi-fold lattice swingaway extension. Offsettable at 0°, 25° and 45°.
Stows alongside base boom section. Maximum tip height: 53,2 m.
*Optional 6,1 m or 12,2 m inserts. Installs between boom nose and bi-fold extension,
non-stowable. Maximum tip height: 59,1 m insert. 65,2 m insert.
Boom Nose
Three nylatron sheaves (four with 60-ton rating) mounted on heavy-duty tapered roller
bearings with removable pin-type rope guards. Quick-reeve type boom nose.
*Optional removable auxiliary boom nose with removable pin type rope guard.
Boom Elevation
One double-acting hydraulic cylinder with integral holding valve provides elevation
from -3° to 78°.
Load Moment & Anti-Two Block System
Standard "Graphic Display" load moment and anti-two block system with audio-visual
warning and control lever lockout. These systems provide electronic display of boom
angle, length, radius, tip height, relative load moment, maximum permissible load, load
indication and warning of impending two-block condition. The standard Work Area
Definition System allows the operator to pre-select and define safe working areas. If the
crane approaches the pre-set limits, audio-visual warnings aid the operator in avoiding
job-site obstructions.
Cab
Full-vision, all-steel fabricated with acoustical lining and tinted safety glass throughout.
Deluxe seat incorporates armrest- mounted hydraulic single-axis controllers. Dash panel
incorporates gauges for all engine functions. Other standard features include: hot water
heater, cab circulating air fan, sliding side and rear windows, sliding skylight with electric
wiper and sunscreen, electric windshield wash/wipe, fire extinguisher and seat belt.
Swing
Planetary swing with foot-applied multi-disc brake. Spring applied, hydraulically-
released swing brake and plunger-type, one position, mechanical house lock operated
from cab.
*Optional 360° mechanical swing lock. Maximum speed: 2,5 RPM.
Counterweight
5 511 kg pinned to superstructure.
Hydraulic system
Three main gear pumps with a combined capacity of 391 LPM, 511 LPM with optional
air conditioning. Maximum operating pressure: 27,6 MPa. Two individual post pressure
compensated valve banks. Return line type filter with full flow by-pass protection and
service indicator. Replaceable cartridge with micron filtration rating of 5/12/16. 500 l
reservoir. Integral oil cooler. System pressure test ports.
Hoist Specifications (HP30-19G)
Main and Auxiliary Hoist
Modèle HP30A-19G: Planetary reduction with automatic spring applied
multi-disc brake. Grooved drum. Electronic hoist drum rotation indicator
and hoist drum cable followers.
Maximum Single Line Pull:
Maximum Single Line Speed:
Maximum Permissible Line Pull:
Rope Diameter:
Rope Length:
Rope Type:
Maximum Rope Stowage:
*Denotes optional equipment
8 246 kg
179 m/min
7 620 kg w/standard 6 x 37 class rope
7 620 kg w/optional 35 x 7 class rope
19 mm
152 m
*Optional 168 m 35 x 7 class rope
6 x 37 class EIPS IWRC
*Optional 35 x 7 class rotation resistant
211 m
Carrier
Chassis
Box section frame fabricated from high-strength, low alloy steel. Integral outrigger
housings and front/rear towing and tie down lugs.
Outriggers
Four hydraulic telescoping single-stage double box beam outriggers with inverted jacks
and integral holding valves. Three position settings, 100%, 50% and fully retracted. All
steel fabricated, quick-release type round outrigger floats, 610 mm diameter. Maximum
outrigger pad load: 36 606 kg.
Outrigger Controls
Controls and crane level indicator located in cab.
Engine (Tier III)
Cummins QSB 6.7L diesel, six cylinders, turbocharged, 179 kW (Gross) at 2 500 rpm.
Maximum torque: 987 N-m at 1 500 RPM
Fuel Tank Capacity
273 l.
Transmission
Spicer powershift with 6 forward and 6 reverse speeds (3 speeds high and 3 speeds
low). Front axle disconnect for 4 x 2 travel.
Electrical System
Two 12-volt maintenance free batteries. 12-volt starting and lighting, circuit breakers,
battery disconnect switch.
Drive / Steering
4 x 4. Fully independent power steering:
Front: Full hydraulic, steering wheel controlled.
Rear: Full hydraulic, switch controlled.
Provides infinite variations of 4 main steering modes: front only, rear only, crab and
coordinated. Rear steer centered indicating light. 4 wheel turning radius 6,7 m.
Axles
Front: Drive/steer with differential and planetary reduction hubs rigid-mounted to frame.
Rear: Drive/steer with differential and planetary reduction hubs pivot-mounted to frame.
Oscillation Lockouts
Automatic full hydraulic lockouts on rear axle permit 203 mm oscillation only with boom
centered over the front.
Brakes
Full hydraulic split circuit brakes operating on all wheels. Spring-applied, hydraulically
released axle-mounted parking brake.
Tyres
29,5 x 25 - 28PR bias earthmover type.
Lights
Full lighting package including turn indicators, head, tail, brake and hazard warning
lights.
Maximum Speed
37 km/h.
Gradeability (Theoretical)
75% (Based on 40 024 kg GVW) 29,5 x 25 tires, pumps engaged, 33,6 m boom, bi-fold
extension, and aux. hoist
Miscellaneous Standard Equipment
Full width steel fenders, dual rear view mirrors, hookblock tiedown, electronic back-up
alarm, light package, front stowage well, tachometer, rear wheel position indicator,
36 000 BTU hot water heater, hoist mirrors, engine distress A/V warning system.
Auxiliary hoist control valve arrangement (less hoist). Cold start aid and immersion type
engine block heater, 120V, 1 500 watt.
*Optional Equipment
*Auxiliary Hoist Package (includes Model HP30A-19G auxiliary hoist with electronic hoist
drum rotation indicator, hoist drum cable follower, 152 m of 19 mm 35 X 7 class wire
rope, auxiliary single sheave boom nose.) *AIR CONDITIONING PACKAGE (includes
hydraulic driven 28 500 BTU air conditioning). *Auxiliary Lighting Package (includes cab
mounted amber flashing light, 360° rotation spotlight and dual base boom mounted
floodlights). *CONVENIENCE PACKAGE (includes in cab LMI light bar). *"CE" Mark
Conformance (includes European boom, battery disconnect switch, 3rd wrap indicator,
electric emergency auxiliary steering, dual axis joystick controllers). *Cross axle
differential locks (front and rear). *Full-length aluminum decking. *Manual pump
disconnect. *Pintle hook - rear. *360 degree NYC style positive swinglock. *Rubber mat
for stowage trough. *PAT datalogger. *Aluminum fender protectors.
